e2e/engine

import { defineEngine, isEngineHandle, type EngineHandle } from 'e2e/engine';

export function defineEngine(spec: Engine): EngineHandle;
export function isEngineHandle(value: unknown): value is EngineHandle;

/** A validated engine: branded, frozen, capabilities computed. */
export interface EngineHandle extends Engine {
  readonly capabilities: ReadonlySet<EngineCapability>;
}

/** The body of one target: typed, model-free, capability-graded. */
export interface Engine {
  /** Engine name, for diagnostics. */
  readonly name: string;
  /**
   * Required implementation version, recorded in reports and sessions.
   * A saved session never restores across engine versions; a cached trace
   * replays across them and re-finds its nodes.
   */
  readonly version: string;
  /**
   * Contract version literal. Additive optional members never bump it;
   * changed required semantics do.
   */
  readonly spiVersion: EngineSpiVersion;
  /**
   * Platform label this engine drives (`web`, `ios`, `android`, or a label of
   * the engine's own). Tests filter on it through `platforms` and tool packs
   * are scoped by it; the harness attaches no meaning to any value. A target
   * inherits it; a target that names a platform of its own must agree with it.
   */
  readonly platform?: string;
  /**
   * Maximum workers for this target, such as the number of devices in a
   * pool. The scheduler applies this cap even when `config.workers` is
   * higher. Omit when the engine has no concurrency limit.
   */
  readonly workers?: number;
  /** capability: observation. */
  observe?(context: OperationContext, options?: EngineObserveOptions): Promise<EngineSnapshot>;
  /**
   * Performs one action on a ref from the newest observation or `locate`,
   * with the platform's actionability checks. Both agent tools and locator
   * actions call this method. A `swipe` on the observation root swipes the
   * viewport.
   *
   * For safe trace replay, throw a retryable
   * `NODE_STALE`-coded error when a ref no longer binds, and an
   * `ACTION_MAY_HAVE_COMMITTED`-coded error when input may have reached the
   * app. The runner never repeats an action that may have committed.
   */
  perform?(ref: NodeRef, action: LocatorAction, context: OperationContext): Promise<void>;
  /**
   * The action kinds `perform` honors, required with it. The harness offers
   * the agent and the `screen` tier exactly these: a kind left out is never
   * presented as a tool that can only decline, and `screen`/`Locator` methods
   * for it fail with `UNSUPPORTED_CAPABILITY` before reaching the engine.
   * `perform` still throws `UNSUPPORTED_CAPABILITY` for a declared kind one
   * particular node cannot take (a `check` on a toggle whose state is unknown).
   */
  readonly actions?: readonly LocatorActionKind[];
  /**
   * capability: location - requires observation. Deterministic locator
   * resolution for the `screen`/`expect` tier: resolve one expression to the
   * nodes it currently matches. The harness owns polling, strictness, and
   * staleness; an engine resolves once, immediately.
   */
  locate?(
    expression: LocatorExpression,
    context: OperationContext,
  ): Promise<readonly SemanticNode[]>;
  /**
   * capability: pointer - requires observation. Performs one pointer action
   * at a viewport point, in the CSS pixels of `SemanticNode.rect`, with no
   * node behind it: the agent's `tap_at` and `hover_at` verbs land here with
   * the point the model named in a screenshot (a shape on a canvas, a pin on
   * a map, a control in a system sheet or one the tree lists), and so do a test's
   * `screen.tapAt`, `screen.swipe({ from, to })`, and `tap({ position })`.
   * Dispatch the pointer at the point as given; the harness has clamped an
   * agent's point to the viewport and validated a test's. Throw
   * `UNSUPPORTED_CAPABILITY` for a declared kind the surface cannot deliver
   * at this particular point.
   */
  performAt?(point: ViewportPoint, action: PointerAction, context: OperationContext): Promise<void>;
  /**
   * The pointer action kinds `performAt` honors, required with it. The
   * harness routes a point-addressed action to the engine only for a kind
   * listed here; an undeclared kind fails with `UNSUPPORTED_CAPABILITY`
   * before reaching the engine.
   */
  readonly pointerActions?: readonly PointerActionKind[];
  /**
   * The surface honors `modifiers` on the `tap`, `doubleTap`, and
   * `secondaryTap` actions `perform` receives. Without it the harness fails
   * an action that carries modifiers with `UNSUPPORTED_CAPABILITY` before it
   * reaches the engine.
   */
  readonly tapModifiers?: boolean;
  /** capability: keyboard - requires observation. Input to whatever holds focus; see `EngineKeyboard`. */
  readonly keyboard?: EngineKeyboard;
  /**
   * Named deterministic surfaces this engine contributes to TestFixtures
   * (a device fixture, a document fixture - anything). Keys become fixture and
   * capability names; `requires: ['<name>']` gates at selection.
   */
  readonly fixtures?: Readonly<Record<string, EngineFixtureFactory>>;
  /** capability: state - opaque snapshot capture/restore for session reuse. */
  readonly state?: EngineStateCapability;
  /** capability: artifacts - screenshots under the attempt directory, and videos there or at a provider. */
  readonly artifacts?: EngineArtifacts;
  /**
   * Checks the app a target declares against what this engine can drive, at
   * config load, synchronously: throw `INVALID_CONFIG` naming
   * `info.targetName` for a field the platform needs and the target left out
   * (a URL, a bundle id) or one it cannot drive. The harness has already
   * checked every field's shape.
   */
  validateApp?(app: EngineAppDeclaration, info: EngineAppCheckInfo): void;
  /**
   * The `secrets.get()` handles the engine's options hold, such as a
   * basic-auth password. The config load checks each names a configured
   * secret (`INVALID_CONFIG` otherwise), and only these resolve through
   * `EngineAttemptContext.resolveSecret`. The handles carry names only, so
   * no value reaches the config digest.
   */
  readonly secrets?: readonly Secret[];
  /** Steering hooks: open, back, restart, reset. */
  readonly session?: EngineSession;
  /**
   * Runs once per target in the runner, after collection and before workers,
   * app commands, and the run's clock start. A run with nothing to run (the
   * test filters left nothing, or `--pass-with-no-tests` on an empty
   * selection) prepares no target, and so calls no `finish`. Download
   * dependencies or boot devices here; report progress through `info.log`.
   * No launch timeout applies. A failure ends the run as an infrastructure
   * error.
   * The result can lower the target's worker cap, for example after
   * discovering how many devices are available.
   */
  prepare?(info: EnginePrepareInfo): Promise<void | EnginePrepareResult>;
  /**
   * Once per run and target in the runner process, after every worker of the
   * target is gone, on every exit path, whenever `prepare` was called.
   * Release what `prepare` acquired for the run (a leased cloud device).
   * Runs within the cleanup budget, never cancelled by an interrupt; a
   * failure is a cleanup-phase run error.
   */
  finish?(info: EngineFinishInfo): Promise<void>;
  /**
   * Once per worker, before the first step; boot devices here, not in a step
   * budget. The same handle can be booted again after `dispose`: a config-held
   * handle outlives an in-process worker, so init MUST work on a disposed
   * engine as it does on a fresh one.
   */
  init?(info: EngineInitInfo): Promise<void>;
  /** Before each attempt: set up per-test isolation. */
  startAttempt?(context: EngineAttemptContext): Promise<void>;
  /**
   * After the body has settled, and again after teardown, before the verdict,
   * within the cleanup budget: report a failure that landed on a path no step
   * awaited (a callback the surface ran for the test: a request interceptor,
   * a native dialog handler). Wait for one still running, then throw its
   * error; the attempt fails with it the way a step would, an error already
   * classified keeping its code. MUST report each failure once.
   */
  settleAttempt?(context: EngineCleanupContext): Promise<void>;
  /**
   * After each attempt, within the cleanup budget: tear that isolation down.
   * MUST be idempotent, and safe to call after a failed `startAttempt`.
   */
  endAttempt?(context: EngineCleanupContext): Promise<void>;
  /**
   * Worker shutdown, within the cleanup budget; failure is a run error. Runs
   * whether or not `init` ran, so it MUST tolerate a cold engine. A live
   * `reuseSignal` permits preserving run-owned resources for a replacement,
   * until that permission is revoked or this hook settles.
   */
  dispose?(context: EngineDisposeContext): Promise<void>;
}

/** What every engine call carries: budget, ids, and who is acting. */
export interface OperationContext {
  /**
   * Aborts when the attempt, or the hook running the call, ends. It does not
   * abort at `timeoutMs`: bound each call by that budget yourself.
   */
  readonly signal: AbortSignal;
  /** Remaining operation budget when the call starts. */
  readonly timeoutMs: number;
  /** The run id. */
  readonly runId: string;
  /** The attempt id. */
  readonly attemptId: string;
  /**
   * Who asked: a test's own deterministic step, or the agent acting on a
   * screen it observed. A deterministic step verifies its outcome with
   * `expect`, so an engine may act as soon as the target holds still; an
   * agent reads the screen right after acting, so an engine may wait for the
   * transition to end first.
   */
  readonly origin: 'test' | 'agent';
}

const engine = kiosk({ host: 'kiosk.local' });
engine.capabilities.has('location'); // true: the engine implements locate

/**
 * Capability names: the closed harness capabilities plus one name per
 * contributed fixture. `actions` is `perform`; `location` is `locate`; both
 * require observation, because their refs live in the observation's id space.
 * `pointer` is `performAt`, an action addressed by a viewport point rather
 * than a node, and requires observation because the point is read off its
 * pixels.
 */
export type EngineCapability =
  | 'observation'
  | 'actions'
  | 'location'
  | 'pointer'
  | 'keyboard'
  | 'state'
  | 'artifacts'
  | (string & {});

/**
 * capability: keyboard - requires observation. Input to whatever holds focus,
 * with no node behind it: the agent's `type` and `press` without a target, and
 * the fallback of its point-addressed `type_at` and `press_at` when the point
 * lands on nothing the tree lists (a field drawn on a canvas, an input a
 * platform flattens out of its accessibility tree). Focus is the app's: the
 * harness tapped first, or the model said the field already has it.
 */
export interface EngineKeyboard {
  /**
   * Types `text` into the focused field as a person typing would, through
   * the platform's keyboard path: a browser dispatches the key events of each
   * character, a device sends the text through its keyboard. Where the
   * platform has key events the app must receive them; setting the value
   * without keystrokes is not a compliant implementation, since
   * `locator.pressSequentially` and the agent's `type` rely on the app
   * reacting as it does to a user. With `replace`, clears the field first
   * (select-all and delete on a keyboard surface; the platform's clear on a
   * device). Throw `NOT_ACTIONABLE` when nothing that accepts text has focus,
   * so the keystrokes are never silently discarded into the document body.
   */
  type(text: string, options: { readonly replace: boolean }, context: OperationContext): Promise<void>;
  /**
   * Sends one key of the contract grammar (`Enter`, `Escape`, `Tab`,
   * `Shift+Tab`, a character) to whatever holds focus. The harness has
   * already validated the key's shape; refuse with `UNSUPPORTED_CAPABILITY`
   * a key the surface cannot deliver.
   */
  press(key: string, context: OperationContext): Promise<void>;
  /** Hides an on-screen keyboard. Platforms without one leave it undefined. */
  dismiss?(context: OperationContext): Promise<void>;
}

async prepare(info) {
  if (info.slots === 0) return; // nothing runs on this target
  info.log('booting devices');
  const devices = await pool.boot(info.slots, { signal: info.signal });
  return { workers: devices.length, env: { KIOSK_DEVICES: devices.join(',') } };
},

/**
 * What `prepare` learned that the run must honour. `workers` replaces the
 * engine's declared cap for this target and run: the surfaces the engine
 * actually provisioned, `1` to `info.slots`. Declared `workers` stays the
 * static answer for engines that know it up front.
 */
export interface EnginePrepareResult {
  /** Lowers the target's worker cap for this run, `1` to `info.slots`. */
  readonly workers?: number;
  /**
   * Variables every worker of this target is spawned with, on top of the
   * run's environment: how a runner-side `prepare` hands what it provisioned
   * (a device pool it discovered) to each worker's `init`. The run's own
   * variables win on a clash.
   */
  readonly env?: Readonly<Record<string, string>>;
}

/**
 * Facts handed to `prepare`, once per run and target in the runner process,
 * before any worker exists.
 */
export interface EnginePrepareInfo {
  /** The run id. */
  readonly runId: string;
  /** The target being prepared. */
  readonly targetName: string;
  /** Directory relative paths in the config resolve against; see `EngineInitInfo.projectRoot`. */
  readonly projectRoot: string;
  /** The app the target declares, as `init` receives it: what a device installs or warms up here. */
  readonly app: EngineAppInfo;
  /**
   * The worker slots the run will start for this target, `0` to `slots - 1`:
   * the run's worker cap, the engine's declared `workers`, and the work units
   * selected for the target, whichever is smallest; `0` when nothing runs on
   * it while another target has work. A run with nothing to run prepares no
   * target. Provision for exactly these slots (boot that many devices of a
   * pool); `init` then finds them ready.
   */
  readonly slots: number;
  /**
   * The run's environment: what every worker is started with. A host may hand
   * the run an environment other than the runner process's own, so anything
   * provisioned here that a worker later looks up by environment (a browser
   * cache location) must be resolved and spawned against this, not
   * `process.env`.
   */
  readonly env: Readonly<Record<string, string | undefined>>;
  /**
   * Aborts on interrupt only. Provisioning has no budget: a first-run
   * download is as long as the network makes it, and cutting it short would
   * fail every test behind it.
   */
  readonly signal: AbortSignal;
  /** Whether the run asked for a visible surface (`--headed`), as `EngineInitInfo` declares it. */
  readonly headed: boolean;
  /**
   * Reports one line of progress. The runner streams it as a `notice` run
   * event, so it reaches the reporter and every host sink instead of being
   * written to a worker's stderr underneath the live status block.
   */
  readonly log: (line: string) => void;
}

async finish(info) {
  await pool.release({ signal: info.signal });
},

/** Handed to `finish`, once per run and target after the last worker is gone, with the cleanup budget of one hook. */
export interface EngineFinishInfo extends EngineCleanupContext {
  /** The run id. */
  readonly runId: string;
  /** The target being finished. */
  readonly targetName: string;
  /** The run's environment, the same `prepare` saw. */
  readonly env: Readonly<Record<string, string | undefined>>;
  /** Reports one line of progress, streamed as a `notice` run event like `prepare`'s. */
  readonly log: (line: string) => void;
}

async init(info) {
  const device = info.env.KIOSK_DEVICES?.split(',')[info.workerSlot];
  info.log(`slot ${info.workerSlot}: ${device}`);
},

/** Run identity and harness-resolved facts handed to `init`, once per worker before the first step. */
export interface EngineInitInfo {
  /** The run id. */
  readonly runId: string;
  /** The target this worker serves. */
  readonly targetName: string;
  /**
   * Directory relative paths in the config resolve against: the config file's
   * directory, or the run's `cwd` for a programmatic config. An engine option
   * naming a file (a build to install) resolves here, never against
   * `process.cwd()`, which an in-process run does not change.
   */
  readonly projectRoot: string;
  /** The app the target declares: the site policy of its URL, and what a device launches. */
  readonly app: EngineAppInfo;
  /**
   * This worker's environment: the run's, plus what this target's `prepare`
   * returned in its result's `env`. Read what `prepare` provisioned from
   * here, never from `process.env`: an in-process worker shares its process
   * with the runner and every other target.
   */
  readonly env: Readonly<Record<string, string | undefined>>;
  /** Whether the run asked for a visible surface (`--headed`). */
  readonly headed: boolean;
  /**
   * This worker's 0-based slot among the target's workers: the lowest slot
   * free when the worker was spawned, so a replacement worker takes over the
   * slot of the one that exited. An engine with several devices hands each
   * slot its own; `config.workers` bounds the slots a target can reach.
   */
  readonly workerSlot: number;
  /** Aborts on interrupt and when init exceeds the launch timeout; init must stop promptly. */
  readonly signal: AbortSignal;
  /**
   * Reports one line of progress. The runner streams it as a `notice` run
   * event, prefixed with the target and worker slot, so it reaches the
   * reporter and every host sink instead of being written to a worker's
   * stderr underneath the live status block. This is where a fact that only
   * exists once the worker is up belongs: the URL a hosted browser or device
   * can be watched at, which simulator a slot got, a version it detected.
   * Meant for `init` itself; a line logged later is still delivered while
   * the worker lives and dropped once it has exited. The line is shown as is
   * in reporters and host sinks, so keep tokens and other secrets out of it
   * (a viewer URL without its credential).
   */
  readonly log: (line: string) => void;
}

async startAttempt(context) {
  const password = await context.resolveSecret(options.password);
  await client.openContext({ password, signal: context.signal });
  context.environment({ device: 'Kiosk 2', os: 'KioskOS 4.1' });
},

/**
 * Per-attempt isolation context. An engine that must give each test a fresh
 * surface (a fresh isolated context per test, a reset device) sets it up in
 * `startAttempt` and tears it down in `endAttempt`.
 */
export interface EngineAttemptContext {
  /** The attempt id. */
  readonly attemptId: string;
  /** Absolute directory every artifact of this attempt is written under. */
  readonly artifactsDir: string;
  /**
   * The plaintext of a secret the engine declared in `secrets`, for an
   * option the engine hands the app itself (basic-auth credentials). A
   * provider runs again on every call. The value, and every value
   * `options.derived` computes from it, join the attempt's redaction before
   * this resolves, so reports, logs, and every observation redact them, and
   * the attempt's text downloads are rewritten. The protection is
   * text only: unlike a fill, it withholds no screenshot or model pixels.
   * A secret the engine did not declare is `SECRET_UNAVAILABLE`.
   */
  readonly resolveSecret: (secret: Secret, options?: ResolveSecretOptions) => Promise<string>;
  /**
   * Aborts with the attempt, and the moment `startAttempt` fails or exceeds
   * the launch timeout: a hook still running then must stop, because the
   * harness ends the attempt's isolation right behind it and may retry.
   */
  readonly signal: AbortSignal;
  /**
   * Reports something the app did on its own while the attempt ran: a
   * console line, an uncaught exception, a request that failed. The harness
   * redacts the text, keeps it with the step that was running (from an event
   * callback outside any step, the step that started last; before the first
   * step, with none), and shows it on the trace page. Call it from the moment `startAttempt` begins until
   * `endAttempt`; entries past a per-attempt cap are dropped.
   */
  readonly appLog: (entry: AppLogEntry) => void;
  /**
   * Reports where the app went on its own, as one line (`navigated to
   * /login`, `the app opened a new tab at /help`): a navigation the engine
   * did not start, a tab, a frame. Shown under the step that was running.
   */
  readonly navigation: (line: string) => void;
  /**
   * Hands the harness a screen for the trace: the capture a `locate`
   * matched against, or one read right after an action. A read after an
   * action is on the action's path, so bound it and skip it where it is
   * expensive; it never fails the action. The trace page shows how each
   * step's screen changed. Refs in it are not valid for `perform`. Absent
   * when the attempt keeps no trace.
   */
  readonly screen?: (snapshot: EngineSnapshot) => void;
  /**
   * What the attempt runs on, such as `{ browser: 'chromium 141.0' }` or
   * `{ device: 'iPhone 16', os: 'iOS 26.0' }`, for the trace page. Later
   * calls add to and overwrite earlier facts.
   */
  readonly environment: (facts: Readonly<Record<string, string>>) => void;
}

/** One line of what the app did during an attempt, as `EngineAttemptContext.appLog` takes it. */
export interface AppLogEntry {
  /**
   * Where it came from: the app's `console`, an `error` nothing caught, the
   * `network`, or the `system` the app runs on (a crash, an OS log).
   */
  readonly source: 'console' | 'error' | 'network' | 'system';
  readonly level: 'error' | 'warning' | 'info';
  /** One line, such as `GET /api/todos 500` or `TypeError: x is undefined`; the harness clips it. */
  readonly text: string;
}

/** How `EngineAttemptContext.resolveSecret` treats what the engine makes of the value. */
export interface ResolveSecretOptions {
  /**
   * The forms of the value the app sees instead of the value itself, for the
   * same redaction under the secret's name: the base64 `user:password` an
   * `Authorization: Basic` header carries, which a page echoing its request
   * headers would otherwise show.
   */
  readonly derived?: (plaintext: string) => readonly string[];
}

async settleAttempt() {
  const running = [...dialogHandlers];
  dialogHandlers.clear();
  await Promise.all(running); // rethrows a handler's failure
},

async endAttempt(context) {
  await client.closeContext({ signal: context.signal });
},

async dispose(context) {
  await client.shutdown({ signal: context.signal });
},

/**
 * Budget of one cleanup hook (`settleAttempt`, `endAttempt`, `dispose`). `signal` aborts when
 * the budget is exhausted, so a hook that cannot finish in time stops instead
 * of running on into the next attempt's setup.
 */
export interface EngineCleanupContext {
  /** Aborts when the cleanup budget is spent. */
  readonly signal: AbortSignal;
  /** Remaining cleanup budget when the call starts. */
  readonly timeoutMs: number;
}

/** Cleanup of one worker, with optional permission to leave run-owned resources for a replacement. */
export interface EngineDisposeContext extends EngineCleanupContext {
  /**
   * A live signal permits reusable resources owned by `prepare` and `finish`
   * to survive this worker. Missing or aborted permission requires final
   * cleanup. Observe revocation until disposal settles. This signal does
   * not cancel cleanup, which remains bounded by `signal` and `timeoutMs`.
   */
  readonly reuseSignal?: AbortSignal;
}

/**
 * One fresh semantic snapshot of the surface under test. The harness owns
 * everything downstream: revision minting, secret redaction, and the
 * observation byte budget apply to every engine equally.
 */
export interface EngineSnapshot {
  /**
   * Where the surface is, as an opaque address the platform understands: a
   * URL on a document platform, the foreground screen or activity on a
   * device, the front window on a desktop. The harness shows it to the model
   * and to the report, anchors trace replay on it, and applies the origin
   * policy to it only when it parses as a URL. Omit when the platform has no
   * notion of a current location.
   */
  readonly location?: string;
  /**
   * The observation tree under one root the engine minted. The root's id MUST
   * be stable for the surface across observations: `perform(root, swipe)` is
   * the viewport swipe, and the harness addresses it from an earlier
   * observation, possibly one taken before a `restart` or `reset`, so the
   * root swipe MUST NOT depend on a live handle from that observation. A
   * platform with several top-level elements (a device's windows) wraps them
   * in a root of its own.
   */
  readonly root: SemanticNode;
  /** The viewport `SemanticNode.rect` and `ViewportPoint` are measured in, in CSS pixels. */
  readonly viewport: ViewportSize;
  /**
   * True when `root` leaves out nodes that are on the surface: the engine
   * stopped reading at a node cap or a depth limit, or could not enter a
   * child document. The harness tells the model the listing is incomplete
   * and never calls such a screen unchanged. Omit or set false for a tree
   * read whole.
   */
  readonly truncated?: boolean;
  /**
   * Whether an on-screen keyboard is showing, as the engine measured it apart
   * from `root`. Set `false` when it measured none, and omit it only when the
   * engine did not measure it.
   */
  readonly keyboardVisible?: boolean;
  /** Semantic capture failed; only fresh, independently masked pixels are evidence. */
  readonly treeUnavailable?: true;
  /** Masked pixels, when requested and producible; omitted otherwise. */
  readonly pixels?: ObservationPixels;
  /** Regions masked in `pixels`; the harness checks it covers every secure node. */
  readonly maskedRegionCount?: number;
}

export interface EngineObserveOptions {
  /** Requests masked viewport pixels for the same revision as the tree. */
  readonly pixels?: boolean;
  /** Permits independently masked pixels to replace a failed semantic capture. */
  readonly pixelFallback?: boolean;
  /** The pixels are compared against a stored screenshot: hold system chrome (a status bar's clock and battery) in a fixed state where the platform can. */
  readonly comparable?: boolean;
}

return {
  treeUnavailable: true,
  root: { ref: rootRef },
  viewport,
  pixels,
};

async perform(ref, action, context) {
  switch (action.kind) {
    case 'tap':
      return client.tap(ref.id, { signal: context.signal });
    case 'swipe':
      return client.scroll(ref.id === rootId ? undefined : ref.id, action.direction);
    default:
      throw new EngineError('UNSUPPORTED_CAPABILITY', `kiosk cannot ${action.kind}`, { retryable: false });
  }
},

/**
 * One deterministic action `perform` carries out on a node. The `swipe`
 * kind on the observation's root node is the viewport swipe: the agent's
 * `scroll` verb and `screen.swipe()` both arrive as `perform(root, swipe)`,
 * so a surface implements scrolling once.
 *
 * `press` takes one key in the `Key` grammar below.
 */
export type LocatorAction =
  | {
      readonly kind: 'tap' | 'doubleTap' | 'secondaryTap';
      /** Keys held for the click; only an engine that declares `tapModifiers` receives it. */
      readonly modifiers?: readonly KeyModifier[];
    }
  | {
      readonly kind:
        | 'check'
        | 'uncheck'
        | 'clear'
        | 'focus'
        | 'hover'
        | 'scrollIntoView';
    }
  | { readonly kind: 'longPress'; readonly durationMs?: number }
  | { readonly kind: 'fill'; readonly value: string; readonly sensitive: boolean }
  | { readonly kind: 'press'; readonly key: Key }
  | { readonly kind: 'selectOption'; readonly value: SelectOption }
  | { readonly kind: 'setInputFiles'; readonly paths: readonly string[] }
  | { readonly kind: 'dragTo'; readonly target: NodeRef }
  | {
      readonly kind: 'swipe';
      readonly direction: ScrollDirection;
      readonly momentum?: Momentum;
    };

/** Every action kind; what an engine declares in `actions`. */
export type LocatorActionKind = LocatorAction['kind'];

/** The closed list of action kinds, in contract order; the type is derived from it. */
export const LOCATOR_ACTION_KINDS = [
  'tap',
  'doubleTap',
  'secondaryTap',
  'longPress',
  'fill',
  'clear',
  'press',
  'check',
  'uncheck',
  'focus',
  'hover',
  'scrollIntoView',
  'selectOption',
  'setInputFiles',
  'dragTo',
  'swipe',
] as const satisfies readonly LocatorActionKind[];

export type PointerAction =
  | { readonly kind: 'tap' | 'doubleTap' | 'secondaryTap' | 'hover' }
  | { readonly kind: 'longPress'; readonly durationMs?: number }
  | { readonly kind: 'dragTo'; readonly target: ViewportPoint }
  | {
      readonly kind: 'swipe';
      readonly direction: ScrollDirection;
      readonly momentum?: Momentum;
    }
  | {
      readonly kind: 'swipeTo';
      readonly target: ViewportPoint;
      readonly durationMs?: number;
    };

/** Every pointer action kind; what an engine declares in `pointerActions`. */
export type PointerActionKind = PointerAction['kind'];

/** The closed list of pointer action kinds, in contract order; the type is derived from it. */
export const POINTER_ACTION_KINDS = [
  'tap',
  'doubleTap',
  'secondaryTap',
  'longPress',
  'hover',
  'dragTo',
  'swipe',
  'swipeTo',
] as const satisfies readonly PointerActionKind[];

parseKey('Control+a'); // { modifiers: ['Control'], key: { kind: 'char', char: 'a' } }
parseKey('Shift+Tab'); // { modifiers: ['Shift'], key: { kind: 'named', name: 'Tab' } }
parseKey('Ctrl+a'); // undefined: Ctrl is not a modifier of the grammar

/**
 * The key grammar of `press`, shared by every engine so a test's key names are
 * portable: zero or more modifiers and one key, joined by `+`.
 *
 * - Modifiers: `Shift`, `Control`, `Alt`, `Meta`, `ControlOrMeta` (Control on
 *   Windows and Linux, Meta on macOS).
 * - Named keys: those in `KEY_NAMES` (`Enter`, `Escape`, `Tab`, `Backspace`,
 *   `Delete`, `ArrowUp`..., `Home`, `End`, `PageUp`, `PageDown`, `Insert`,
 *   `Space`, `F1`..`F12`).
 * - Any single printable character (`a`, `A`, `1`, `$`), typed as itself.
 *
 * `Control+a`, `Shift+Tab`, `Enter`, `$`. A platform without a key maps it
 * or throws `UNSUPPORTED_CAPABILITY`; it never reinterprets the spelling.
 * `parseKey` is the one parser, exported so no engine carries its own.
 */
export type Key = string;

export const KEY_MODIFIERS = ['Shift', 'Control', 'Alt', 'Meta', 'ControlOrMeta'] as const;

export const KEY_NAMES = [
  'Enter',
  'Escape',
  'Tab',
  'Backspace',
  'Delete',
  'Insert',
  'Space',
  'ArrowUp',
  'ArrowDown',
  'ArrowLeft',
  'ArrowRight',
  'Home',
  'End',
  'PageUp',
  'PageDown',
  'F1',
  'F2',
  'F3',
  'F4',
  'F5',
  'F6',
  'F7',
  'F8',
  'F9',
  'F10',
  'F11',
  'F12',
] as const;

/** One parsed `press` key: its modifiers and either a named key or a single character. */
export interface ParsedKey {
  /** Modifiers, in the order written. */
  readonly modifiers: readonly KeyModifier[];
  /** The key itself. */
  readonly key: { readonly kind: 'named'; readonly name: KeyName } | { readonly kind: 'char'; readonly char: string };
}

export function parseKey(key: string): ParsedKey | undefined;

validateApp(app, { targetName }) {
  if (app.url === undefined) {
    throw new ConfigurationError('INVALID_CONFIG', `target "${targetName}" needs app.url`);
  }
},

/**
 * The app a target declares, as its engine reads it at config load: what it
 * is and where it is served. `EngineAppInfo` (below) is what `prepare` and
 * `init` receive; the declaration adds the URL, which a surface never gets.
 */
export type EngineAppDeclaration = EngineAppInfo & {
  /** Base URL the target opens, as declared; see `TargetApp.url`. */
  readonly url?: string;
};

/** Handed to `Engine.validateApp` beside the declaration. */
export interface EngineAppCheckInfo {
  /** The target declaring the app, for the message of a refusal. */
  readonly targetName: string;
}

/** A permission's state when the app launches: held, refused, or not asked for yet, so the OS asks again. */
export type AppPermissionState = 'grant' | 'deny' | 'reset';

if (sameSite(request.url, info.app.site ?? '')) request.headers.set('x-api-key', key);

/**
 * The app the harness resolved from the target's declaration, handed to
 * `prepare` and `init`: the site policy for the decisions only a surface can
 * make (which nested documents enter an observation, which requests carry
 * injected credentials), and what a device launches.
 */
export interface EngineAppInfo {
  /**
   * The app URL's registrable domain, as read by `siteOf`. Use `sameSite`
   * to scope secret fills, injected headers, and observed child frames.
   * Absent when the app has no URL. The runner passes navigation URLs
   * separately through `session.open`.
   */
  readonly site?: string;
  /** The installed app to launch, as the target declared it. */
  readonly bundleId?: string;
  /** The build to install, as the target declared it; relative to `projectRoot`. */
  readonly appPath?: string;
  /** Arguments every fresh launch passes the app. */
  readonly launchArguments?: readonly string[];
  /** Permissions the app holds on every fresh launch, by name. */
  readonly permissions?: Readonly<Record<string, AppPermissionState>>;
}

session: {
  async back(context) { await client.back({ signal: context.signal }); },
  async restart(context) { await client.relaunch(bundleId, { signal: context.signal }); },
},

/**
 * Steering hooks behind the universal `app` fixture and the agent's
 * `navigate` verb. The app itself is the target's `app`, handed over as data;
 * node actions never live here, they are `perform`.
 *
 * `restart` and `reset` open nothing on an addressable surface: they end at
 * a fresh surface with no location shown, and the harness reopens the app
 * through `open` when the target has an address. A surface therefore never
 * needs to know the app's URL, and an unreachable app after a restart is
 * reported the same way as on first open. A surface without `open` (a
 * device with a pinned app) relaunches the app inside `restart` and `reset`
 * itself, since nothing else will.
 */
export interface EngineSession {
  /**
   * Opens one URL the harness already resolved against the base URL and the
   * origin policy. Absent on a surface without addressable locations.
   */
  open?(url: string, context: OperationContext): Promise<void>;
  /** Navigates back once in the surface's history. */
  back?(context: OperationContext): Promise<void>;
  /** Recreates the execution context, keeping persisted state. */
  restart?(context: OperationContext): Promise<void>;
  /** Clears persisted client state and recreates the execution context. */
  reset?(context: OperationContext): Promise<void>;
}

throw new EngineError('NODE_STALE', `node ${ref.id} is gone`, { retryable: true });

export class EngineError extends Error {
  constructor(code: EngineErrorCode, message: string, options: { retryable: boolean; cause?: unknown });
  /** One of `ENGINE_ERROR_CODES`. */
  readonly code: EngineErrorCode;
  /** Whether the runner may re-resolve and retry; only `RETRYABLE_ENGINE_ERROR_CODES` can be. */
  readonly retryable: boolean;
}

/** The closed engine error code set; the type is derived from it, so the two cannot drift. */
export const ENGINE_ERROR_CODES = [
  'NODE_STALE',
  'FRAME_NOT_FOUND',
  'FRAME_AMBIGUOUS',
  'NOT_ACTIONABLE',
  'ACTION_MAY_HAVE_COMMITTED',
  'OPERATION_TIMEOUT',
  'CANCELLED',
  'UNSUPPORTED_CAPABILITY',
  'INVALID_STATE',
  'ENGINE_FAILURE',
] as const;

/** One of `ENGINE_ERROR_CODES`. */
export type EngineErrorCode = (typeof ENGINE_ERROR_CODES)[number];

/**
 * The only codes that may be retryable: both describe a repeatable read. Any
 * other retryable claim, from this module's class or a foreign copy of it, is
 * coerced to a non-retryable `ENGINE_FAILURE`.
 */
export const RETRYABLE_ENGINE_ERROR_CODES: ReadonlySet<EngineErrorCode> = new Set([
  'NODE_STALE',
  'FRAME_NOT_FOUND',
]);

throw new TestError('ASSERTION_FAILED', 'expected the receipt to print');

/** The runner's error base: `category` sets the exit code, `code` names the cause. */
declare class E2EError extends Error {
  readonly category: 'test' | 'configuration' | 'infrastructure' | 'internal' | 'interrupted';
  readonly code: string;
  readonly retryable: boolean;
}

/** A test failure: ASSERTION_FAILED, INVALID_LOCATOR, ACTION_FAILED, ... */
export class TestError extends E2EError {
  constructor(code: string, message: string, options?: { retryable?: boolean; cause?: unknown });
}
/** POLICY_DENIED, APP_URL_REQUIRED, UNSUPPORTED_CAPABILITY, ... */
export class ConfigurationError extends E2EError {
  constructor(code: string, message: string, options?: { cause?: unknown });
}
/** The surface itself failed: BROWSER_INSTALL_FAILED, ... */
export class InfrastructureError extends E2EError {
  constructor(code: string, message: string, options?: { cause?: unknown });
}

export function toTextPattern(match: TextMatch, options?: { exact?: boolean }): TextPattern;
export function matchesText(actual: string, pattern: TextPattern): boolean;
export function describePattern(pattern: TextPattern): string;

const pattern = toTextPattern(/total/i);
matchesText('Order total', pattern); // true
describePattern(pattern); // '/total/i'

export function resolveExpression(
  expression: LocatorExpression,
  nodes: readonly SemanticNode[],
  options?: ResolveExpressionOptions,
): SemanticNode[];

async locate(expression) {
  const screen = await client.snapshot();
  return resolveExpression(expression, screen.nodes);
},

export function urlMatches(
  current: string,
  expected: string | RegExp,
  baseHref: string,
  ignoreCase?: boolean,
): boolean;

urlMatches('https://shop.test/cart', '/cart', 'https://shop.test/'); // true

export function siteOf(hostname: string): string;
export function sameSite(url: string | URL, site: string): boolean;

export function pollCondition(options: PollConditionOptions): Promise<void>;

const deadline = new Deadline(context.timeouts.assertion);
await pollCondition({
  deadline,
  signal: context.signal,
  negated: false,
  evaluate: async () => (await read(context.operation(deadline.remaining()))) === 'Paid',
  onTimeout: (cause) => new TestError('ASSERTION_FAILED', 'status never became Paid', { cause }),
});

export function validateJsonValue(value: unknown, label: string, rules?: JsonValueRules): void;

validateJsonValue(result, 'kiosk.evaluate result', { maxDepth: 32 });

export function rejectUnknownKeys(
  label: string,
  value: object,
  keys: readonly string[],
  code?: 'INVALID_CONFIG' | 'INVALID_ARGUMENT', // default: 'INVALID_CONFIG'
): void;

rejectUnknownKeys('web()', options, ['browser', 'viewport']);
// web() has unknown key "viewprt"; did you mean "viewport"?

export function rejectUnknownOptions(
  api: string,
  options: object | undefined,
  known: readonly string[],
  code?: 'INVALID_ARGUMENT' | 'INVALID_LOCATOR', // default: 'INVALID_ARGUMENT'
): void;

rejectUnknownOptions('kiosk.print', options, ['copies']);

obj({ a: 1, b: undefined, c: 3 }); // { a: 1, c: 3 }

export function raceAbort<T>(work: Promise<T> | (() => Promise<T>), signal: AbortSignal, label: string): Promise<T>;
export function withTimeout<T>(promise: Promise<T>, timeoutMs: number, onTimeout: () => Error): Promise<T>;
export function withinCleanupBudget(
  promise: Promise<unknown>,
  budget: { readonly signal: AbortSignal; readonly timeoutMs: number },
): Promise<void>;

await raceAbort(() => client.tap(ref.id), context.signal, 'kiosk tap');

const password = isSecret(options.password)
  ? await context.resolveSecret(options.password)
  : options.password;

state: {
  async capture(context) {
    return { format: 'kiosk-storage', version: 1, data: await client.exportStorage(context) };
  },
  async restore(state, context) {
    await client.replaceStorage(state.data, context);
  },
},

/**
 * An opaque, restorable snapshot of an engine's state. `data` is JSON the
 * harness never inspects - a document platform's storage state, a device's app state, a
 * desktop's window state all satisfy it identically. `format`/`version` let a
 * engine reject a snapshot it can no longer read.
 */
export interface EngineState {
  /** Engine-defined format name. */
  readonly format: string;
  /** Format version, for rejecting a snapshot the engine can no longer read. */
  readonly version: number;
  /** Opaque JSON the runner never inspects. */
  readonly data: unknown;
  /** Earliest moment the state is known to be invalid, if the engine knows one. */
  readonly expiresAt?: string;
}

/**
 * Platform-neutral state capture and restore. A setup test captures a
 * snapshot; an ordinary test restores it at launch.
 *
 * Snapshots are credentials: cookies, tokens, and storage that authenticate
 * the app under test. The duties split at the seam. The harness owns the
 * snapshot from the moment `capture` returns: it encrypts it at rest with a
 * per-run AES-256-GCM key that never touches disk, stores it under the run's
 * private session directory, binds it to the run, target, engine, and app
 * identity, and deletes it when the run ends; it never logs it, reports it,
 * digests it, or sends it to a model. An engine MUST NOT persist, cache, or
 * log a snapshot on its own, MUST NOT echo snapshot contents in an error
 * message, and MUST treat `restore` as a replacement of the surface's whole
 * persisted state, never a merge, so a restored session cannot leak into the
 * next attempt.
 */
export interface EngineStateCapability {
  /** Captures the surface's persisted state. */
  capture(context: OperationContext): Promise<EngineState>;
  /** Replaces the surface's persisted state with `state`. */
  restore(state: EngineState, context: OperationContext): Promise<void>;
}

artifacts: {
  async screenshot(_label, context) {
    // The label comes from test code, so it never becomes part of the path.
    shots += 1;
    const path = `screenshots/${String(shots).padStart(3, '0')}.png`;
    await client.capture(join(artifactsDir, path), context);
    return path;
  },
},

/**
 * Evidence capture. Paths are relative to the attempt artifact directory the
 * engine received in `startAttempt`.
 */
export interface EngineArtifacts {
  /** Captures a redacted screenshot; secure fields are masked at the source. */
  screenshot(label: string | undefined, context: OperationContext): Promise<string>;
  /**
   * Starts recording the surface for the attempt. Declared together with
   * `stopVideo`. A surface that has nothing to show yet (no page open) may
   * defer the actual capture to the moment it does; the segments returned by
   * `stopVideo` say when each one began.
   */
  startVideo?(context: OperationContext): Promise<void>;
  /**
   * Stops recording and returns every segment written, in order. One segment
   * is the common case; a surface whose recording is bound to a page returns
   * one per page the attempt showed (a restart or a state reset opens a new
   * one). An attempt that never showed anything returns none.
   */
  stopVideo?(context: OperationContext): Promise<readonly VideoSegment[]>;
}

/**
 * One recorded video of an attempt: a file the engine wrote into the attempt
 * artifact directory, or a recording a hosted service keeps and links to.
 */
export type VideoSegment = VideoFile | VideoLink;

/** A video file in the attempt artifact directory. */
export interface VideoFile {
  /** Path relative to the attempt artifact directory. */
  readonly path: string;
  /** When the segment started recording, as an ISO timestamp; its first frame is at or just after it. */
  readonly startedAt: string;
}

/** A recording a hosted service keeps, by URL: the report links to it and the runner never downloads it. */
export interface VideoLink {
  /** `http(s)` URL of the recording. */
  readonly url: string;
  /** Media type of what the URL serves: `video/mp4`, or `text/html` for a player page. */
  readonly mediaType: string;
  /** When the recording started, as an ISO timestamp; its first frame is at or just after it. */
  readonly startedAt: string;
}

async stopVideo(context) {
  if (recording === undefined) return [];
  return [await stopProviderRecording(recording, { artifactsDir, provider: 'browser provider "kernel"', leaseId, signal: context.signal })];
},

/** Handed to a provider's `record`, once per attempt that records video. */
export interface ProviderRecordContext {
  readonly runId: string;
  readonly targetName: string;
  /** The attempt the recording covers. */
  readonly attemptId: string;
  /** The run's environment, the same the provider's `acquire` saw. */
  readonly env: Readonly<Record<string, string | undefined>>;
  /** Aborts when the attempt is cancelled or its launch budget is spent. */
  readonly signal: AbortSignal;
}

/** A recording a provider's service makes of the browser or device it leased, as `record` started it. */
export interface ProviderRecording {
  /** When the recording started, as an ISO timestamp; its first frame is at or just after it. */
  readonly startedAt: string;
  stop(context: ProviderRecordingStopContext): Promise<ProviderRecordingResult>;
}

/** Handed to `ProviderRecording.stop`, once per recording. */
export interface ProviderRecordingStopContext {
  /** Absolute directory, already created, a recording written as a file goes into. */
  readonly dir: string;
  /** Aborts when the cleanup budget is spent. */
  readonly signal: AbortSignal;
}

/**
 * What a stopped recording became: a file the provider wrote into the
 * directory it was given, by name, or a recording its service keeps, by
 * `http(s)` URL and media type.
 */
export type ProviderRecordingResult =
  | { readonly file: string }
  | { readonly url: string; readonly mediaType: string };

export function isProviderRecording(value: unknown): value is ProviderRecording;

export function stopProviderRecording(
  recording: ProviderRecording,
  target: {
    /** Absolute attempt artifact directory; a file recording goes into its `video` directory. */
    readonly artifactsDir: string;
    /** The provider as error messages name it: `browser provider "kernel"`. */
    readonly provider: string;
    /** The lease the recording covers, named in error messages. */
    readonly leaseId: string;
    readonly signal: AbortSignal;
  },
): Promise<VideoSegment>;

/**
 * A contributed fixture: any record of async methods, sync accessors, and
 * nested namespaces, declared through context.fixture so its metadata controls
 * labels, deadlines and verification. The factory must return the declared
 * surface; a plain one is rejected with INVALID_CONFIG.
 */
export type EngineFixtureFactory = (context: EngineFixtureContext) => object;

/** Context handed to a contributed fixture factory, once per attempt. */
export interface EngineFixtureContext {
  /** The target the fixture serves. */
  readonly targetName: string;
  /** Records the declared operations before invoking them; undeclared accessors retain their identity. */
  fixture<T extends object>(name: string, surface: T, operations: FixtureOperations<T>): T;
  readonly app: EngineAppInfo & {
    /**
     * Resolves a navigation target against the base URL. Throws
     * `APP_URL_REQUIRED` when the target declares no URL and `POLICY_DENIED`
     * for any scheme but `http:` and `https:` (`about:blank` aside), so a
     * fixture never re-implements the rule the harness owns.
     */
    resolveUrl(url: string): string;
  };
  /** Harness budgets, for fixtures that poll or navigate. */
  readonly timeouts: {
    readonly test: number;
    readonly action: number;
    readonly assertion: number;
  };
  /**
   * The running phase's signal: the attempt's through `beforeEach` and the
   * body, then a fresh one per `afterEach` hook so teardown can still drive
   * the app after a body timeout. Read it per call; a fixture factory that
   * captures it once keeps a signal that is dead by teardown.
   */
  readonly signal: AbortSignal;
  /** Per-call operation budget: the action timeout (or an explicit one) plus the attempt signal. */
  operation(timeoutMs?: number): OperationContext;
  /** Registers a file the current step produced under the attempt artifact directory. */
  attachArtifact(
    kind: 'screenshot' | 'video' | 'download' | 'log',
    relativePath: string,
  ): void;
  /** Records the viewport the current step established. */
  attachViewport(viewport: { width: number; height: number; scale: number }): void;
  /** Mints a public locator from a raw expression (a platform selector, say). */
  locator(expression: LocatorExpression): Locator;
  /** Mints a screen scope whose every query is wrapped by `scope` (a nested document, say). */
  screen(scope: (expression: LocatorExpression) => LocatorExpression): Screen;
  /**
   * Attaches an expectation surface to a fixture object so `expect(fixture)`
   * returns it. The harness records every matcher call as an assertion step
   * named `expect.<matcher>`; the factory only decides what the matchers mean.
   */
  expectable<T extends object, E extends object>(target: T, factory: () => E): T & Expectable<E>;
}

/** Explicit recording policy for one async fixture method. Arguments enter reports only through label. */
export interface FixtureOperation<Args extends unknown[] = unknown[]> {
  readonly kind: 'resource' | 'assertion';
  readonly label?: (...args: Args) => string;
  /** Action timeout by default; false when the method owns its assertion/navigation deadline. */
  readonly timeout?: number | false | ((...args: Args) => number | undefined);
  /** Assertions verify by default; waits may opt in as well. */
  readonly verifies?: boolean;
}

/** Only declared async methods are recorded. Sync accessors pass through unchanged. */
export type FixtureOperations<T extends object> = {
  readonly [Key in keyof T]?: T[Key] extends (...args: infer Args) => Promise<unknown>
    ? FixtureOperation<Args>
    : T[Key] extends object ? FixtureOperations<T[Key]> : never;
};
