Testing Face ID and fingerprint unlock with e2e

An Expo lock screen that unlocks with Face ID or a fingerprint and falls back to a PIN, tested end to end on iOS and Android with e2e.

How it works

• Unlock (src/hooks/use-lock.ts): asks for Face ID on iOS or a fingerprint on Android through expo-local-authentication. The prompt is the system's; the app only learns whether it matched.
• PIN (src/components/pin-form.tsx): takes over after a failed match, after Use PIN, or at once when nothing is enrolled.
• Background: the app locks again as soon as it goes to the background.

The app has its own PIN, like a banking app, so the device's passcode isn't offered as a fallback. The PIN comes from .env.local and is built into the app, which is fine for a demo; a real app checks it on its server. There's no backend.

Faces and fingers

Getting started

You need Node 22.22.3+ or 24.8+, and Xcode with an iOS simulator that has Face ID or the Android SDK with an emulator (Expo's setup guide).

npm install
cp .env.example .env.local
npm run ios

Set EXPO_PUBLIC_PIN in .env.local to any 6 digits but 000000. npm run ios (or npm run android) builds the app, installs it on the simulator, and starts Metro. The app needs a native build, so it doesn't run in Expo Go.

Android emulator

Android shows a biometric prompt only on a device with a screen lock, and the tests touch the sensor with finger 1. Set both up once, with the emulator running:

1. Set a screen lock: adb shell locksettings set-pin 1111.

2. Open fingerprint setup with adb shell am start -a android.settings.FINGERPRINT_ENROLL, enter 1111, and tap through to "Touch the sensor".

3. Touch it with finger 1 until the fingerprint is added, then tap Done:

   for i in $(seq 15); do adb emu finger touch 1; sleep 0.5; adb emu finger remove; sleep 0.5; done

4. Keep the screen on, so the lock screen stays away during tests: adb shell svc power stayon true.

End-to-end tests

tests/biometrics.e2e.ts runs on iOS and Android. A test can't show a face or touch a sensor, so e2e's device fixture plays them (device.setBiometrics), takes Face ID off the simulator (device.enrollBiometrics), and sends the app home and back (device.home, device.openApp). After a failed match, the agent reads the system's prompt and taps its Use PIN, since iOS and Android word and build it differently. The app's own screens use exact locators, and the PIN is typed as an e2e secret, so it stays out of reports and logs.

The tests need EXPO_PUBLIC_PIN, and the agent test also needs a Vercel AI Gateway key, AI_GATEWAY_API_KEY, both in .env.local. Without them they skip. Android has no way to unenroll a fingerprint from a test, so the "nothing enrolled" test runs on iOS only. After npm run ios or npm run android, run:

npx e2e run --target ios
npx e2e run --target android

Without --target, both run, in about a minute and a half and under a cent. The runner starts Metro if it isn't running. To pick the simulator and emulator, or to move Metro off port 8081, set IOS_DEVICE, ANDROID_DEVICE, or METRO_PORT in .env.local; build the Android app with npx expo run:android --port <port> to match.
